ACM1602B SERIES LCD MODULE
AZ DISPLAYS, INC.
09/17/99
1
1.0 MECHANICAL SPECS
1. Overall Module Size
84.0mm(W) x 44.0mm(H) x max 13.5mm(D) for LED backlight
version
84.0mm(W) x 44.0mm(H) x max 9.5mm(D) for reflective version
0.56mm(W) x 0.61mm(H)
0.61mm(W) x 0.66mm(H)
1/16
KS0066
TN, STN
Reflective, Transflective, Transmissive
LED
Standard ( 0oC ~ 50oC),Wide(-20oC ~ 70oC)
2. Dot Size
3. Dot Pitch
4. Duty
5. Controller IC
6. LC Fluid Options
7. Polarizer Options
8. Backlight Options
9. Temperature Range Options
2.0 ABSOLUTE MAXIMUM RATINGS
Item
Symbol
Min
Typ
Max
Unit
Operating temperature (Standard)
Top
0
-
50
oC
Storage temperature (Standard)
Tst
-10
-
60
oC
Operating temperature (Wide temperature)
Top
-20
-
70
oC
Storage temperature (Wide temperature)
Tst
-30
-
80
oC
Input voltage
Vin
Vss
Vdd
V
Supply voltage for logic
Vdd- Vss
2.7
-
5.5
V
Supply voltage for LCD drive
Vdd- Vo
3.0
4.6
6.5
V
