參數資料
| 型號： | 933500170163 |
| 廠商： | NXP SEMICONDUCTORS |
| 元件分類： | 二極管(射頻、小信號、開關、功率) |
| 英文描述： | SILICON, SIGNAL DIODE |
| 封裝： | HERMETIC SEALED, GLASS PACKAGE-2 |
| 文件頁數： | 6/8頁 |
| 文件大小： | 54K |
| 代理商： | 933500170163 |
1996 Jun 07
6
Philips Semiconductors
Product specication
Fast soft-recovery
controlled avalanche rectiers
BYV95 series
Dotted line: Tj = 175 °C.
Solid line: Tj =25 °C.
Fig.8
Forward current as a function of forward
voltage; maximum values.
handbook, halfpage
01
23
8
6
IF
VF (V)
2
0
4
MGC577
(A)
Fig.9
Reverse current as a function of junction
temperature; maximum values.
handbook, halfpage
10 3
10
2
10
1
10 1
200
0
MGC574
100
Tj ( C)
o
IR
(
A)
VR =VRRMmax.
f = 1 MHz; Tj =25 °C.
Fig.10 Diode capacitance as a function of reverse
voltage; typical values.
handbook, halfpage
1
MGC582
10
102
10
3
1
10
2
10
Cd
VR (V)
(pF)
Fig.11 Device mounted on a printed-circuit board.
Dimensions in mm.
handbook, halfpage
MGA200
3
2
7
50
25
50
