9-1415537-5 Product Details
9-1415537-5
Active
Mid-Ran ge PC Board Re lays
Alway s EU RoHS/ELV Compliant
(Statement of Compliance)
Product Highlights:
SR6 Series
Contact Arrangement = 5 Form A + 1 Form B, 5PST-NO +
SPST-NC, 5 N/O + 1 N/C
Contact Current Rating = 8 Amps.
Monostable Coil Magnetic System
Without Coil Suppression Diode
View all Features | Find Similar Products
Previous 1 ... 16 17 [18] 19 20 Next
Quick Links
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact Us About This Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
Safety Relay SR6 (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
List all Documents
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Ple ase u se th e Produ ct Drawin g for all de sign activity)
Product Type Features:
Termination Type = Through Hole
Comment = Forcibly Guided Contacts according EN 50205
Electrical Characteristics:
Contact Current Rating (Amps.) = 8
Coil Resistance (?) = 1620
Coil Power, Nominal (mW) = 800
Actuating System = DC
Coil Power, Nominal (W) = 0.80
Input Voltage (VDC) = 36
Dielectric Strength - Coil Contacts (V rms) = 3000
Tracking Resistance of Relay Base = CTI250
Coil Rating = Sensitive
Body Related Features:
Series = SR6
Polarized = No
Enclosure Color = Clear
Contact Related Features:
Mounting Options = PC Board
Enclosure = Immersion Cleanable
FCC Part 68 Isolation = No
Relay Type = PCB
Contact Material = Silver Tin Oxide, Gold Plated
Contact Finish = Gold Plate
Approx. Dimensions (L x W x H) (mm [in]) = 55.0 x 16.5 x 16.5 [2.165 x
Housing Related Features:
Pick-Up (V) = 27
Drop-Out (V) = 3.6
Configuration Related Features:
Contact Arrangement = 5 Form A + 1 Form B, 5PST-NO + SPST-NC, 5 N/O
+ 1 N/C
Coil Magnetic System = Monostable
Coil Suppression Diode = Without
Coil Selection Criteria = Nominal Voltage
Coil Latching = Without
LED Indicator = Without
Number of Coils = 1
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 240C, Wave solder
capable to 260C
RoHS/ELV Compliance History = Always was RoHS compliant
Packaging Related Features:
Packaging Method = Carton Bar
Other:
