9-1415534-4 Product Details
9-1415534-4
Active
Mid-Ran ge Plu g-in /Pan e l Mou n t Ge n e ral Pu rpose Re lays
Converted to EU RoHS/ELV Compliant
(Statement of Compliance)
Product Highlights:
PT Series
Contact Arrangement = 2 Form C, DPDT, 2 C/O
Contact Current Rating = 12 Amps.
Monostable Coil Magnetic System
Input Voltage = 230 VAC
View all Features | Find Similar Products
Previous 1 ... 16 [17] 18 19 20 Next
Quick Links
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact Us About This Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
Relay Package Package PT (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
List all Documents
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Ple ase u se th e Produ ct Drawin g for all de sign activity)
Product Type Features:
Termination Type = .110 x .032 Quick Connect Terminals
Comment = Mechanical Indicator; Relay Package includes PT Relay, DIN
Rail Socket, Plastic Retainer Clip, Module and Marking Tag.
Electrical Characteristics:
Contact Current Rating (Amps.) = 12
Input Voltage (VAC) = 230
Coil Resistance (?) = 19465
Actuating System = AC
Coil Power, Nominal (VA) = 1.00
Dielectric Strength - Coil Contacts (V rms) = 2500
Body Related Features:
Series = PT
Polarized = No
Enclosure Color = Clear
Contact Related Features:
Mounting Options = Solder Lugs, Socket
Enclosure = Flux-Tight
FCC Part 68 Isolation = No
Relay Type = Power
Contact Material = Silver Nickel 90/10
Approx. Dimensions (L x W x H) (mm [in]) = 28.00 x 22.50 x 29.00 [1.103
x .886 x 1.142]
Test Button = With
Neon Indicator = LED
Indicator Lamp = With
Housing Related Features:
Pick-Up (V) = 184
Drop-Out (V) = 69
Configuration Related Features:
Contact Arrangement = 2 Form C, DPDT, 2 C/O
Coil Magnetic System = Monostable
Coil Suppression Diode = Without
Coil Selection Criteria = Nominal Voltage
Coil Latching = Without
LED Indicator = With
Number of Coils = 1
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Converted to comply with RoHS
directive
Packaging Related Features:
Packaging Method = Carton Bar
Other:
Electrical Spacing = 4.0mm Clearance 4.0mm Creepage
