Band-Pass & Band-Reject
828BP & 828BR Series
8-Bit Programmable
4-Pole Pair Filters
25 Locust St, Haverhill, Massachusetts 01830 Tel: 800/252-7074, 978/374-0761 FAX: 978/521-1839
e-mail: sales@freqdev.com Web Address: http://www.freqdev.com
Model
Product Specifications
828BP4
Band-Pass
Model
Product Specifications
828BR4
Band-Reject
Size
2.0" x 2.0" x 0.5"
Size
2.0" x 2.0" x 0.5"
Range fo
1 Hz to 25.6 kHz
Range fo
1 Hz to 25.6 kHz
Available "Q’s"
1
1, 2, 5, 10
Available "Q’s"
1
3, 10
Q Accuracy
±10%
Q Accuracy
±10%
Theoretical Transfer
Characteristics
Appendix A
Pages 41 & 42
Theoretical Transfer
Characteristics
Appendix A
Pages 43
Notch Attenuation
45 db typ.
Pass-Band Gain
(non-inverting)
0± 0.25 dB typ.
0± 0.50 dB max.
Pass-Band Gain
(non-inverting)
0± 0.25 dB typ.
0± 0.50 dB max.
Attenuation Rate
24 dB/octave
Attenuation Rate
24 dB/octave
Center Frequency
fo
±2% max.
Center Frequency
fo
±2% max.
Stability
±0.01%/°C
Stability
±0.01%/°C
Filter Mounting
Assembly
FMA-02A
Filter Mounting
Assembly
FMA-02A
1. Q – Quality Factor for band-pass and band-reject filters. Q = f
O
/(f
H
-f
L
)
f
O
=
√
f
H
f
L
3
