FEATURES
Member of the Texas Instruments Widebus
Family
Bus Hold on Data Inputs Eliminates the Need
for External Pullup/Pulldown Resistors
Latch-Up Performance Exceeds 250 mA Per
JESD 17
ESD Protection Exceeds JESD 22
– 2000-V Human-Body Model (A114-A)
– 200-V Machine Model (A115-A)
– 1000-V Charged-Device Model (C101)
DESCRIPTION/ORDERING INFORMATION
This device contains four independent noninverting
buffers and an 8-bit noninverting bus transceiver and
D-type latch, designed for 1.65-V to 3.6-V V
CC
operation.
DGG, DGV, OR DL PACKAGE
(TOP VIEW)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
TOE
D1
A1
GND
Y1
A2
V
CC
D2
A3
GND
Y2
A4
D3
A5
GND
Y3
A6
V
CC
D4
A7
GND
A8
Y4
LE
DIR
B1
Q1
GND
B2
Q2
V
CC
B3
Q3
GND
B4
Q4
B5
Q5
GND
B6
Q6
V
CC
B7
Q7
GND
Q8
B8
LOE
SN74ALVCH16973
8-BIT BUS TRANSCEIVER AND TRANSPARENT D-TYPE LATCH
WITH FOUR INDEPENDENT BUFFERS
SCES435B–APRIL 2003–REVISED SEPTEMBER 2004
The SN74ALVCH16973 is particularly suitable for
demultiplexing an address/data bus into a dedicated
address bus and dedicated data bus. The device is
used
where
there
is
asynchronous
communication between the A and B data bus, and
the address signals are latched and buffered on the
Q bus. The control-function implementation minimizes
external timing requirements.
bidirectional
This device can be used as one 4-bit buffer, one 8-bit
transceiver,
or
one
8-bit
transmission from the A bus to the B bus or from the
B bus to the A bus, depending on the logic level at
the direction-control (DIR) input. The transceiver
output-enable (TOE) input can be used to disable the
transceivers so that the A and B buses effectively are
isolated.
latch.
It
allows
data
ORDERING INFORMATION
T
A
PACKAGE
(1)
ORDERABLE PART NUMBER
SN74ALVCH16973DL
SN74ALVCH16973DLR
SN74ALVCH16973DGGR
SN74ALVCH16973DGVR
TOP-SIDE MARKING
Tube
Tape and reel
Tape and reel
Tape and reel
SSOP - DL
ALVCH16973
-40
°
C to 85
°
C
TSSOP - DGG
TVSOP - DGV
ALVCH16973
VH973
(1)
Package drawings, standard packing quantities, thermal data, symbolization, and PCB design guidelines are available at
www.ti.com/sc/package.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
Widebus is a trademark of Texas Instruments.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Copyright 2003–2004, Texas Instruments Incorporated
