73K321L
CCITT V.23, V.21
Single-Chip Modem
13
ELECTRICAL SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
PARAMETER
RATING
VDD Supply Voltage
Storage Temperature
7V
-65 to 150
°
C
260
°
C
-0.3 to VDD + 0.3V
Soldering Temperature (10 sec.)
Applied Voltage
NOTE: All inputs and outputs are protected from static charge using built-in, industry standard protection devices
and all outputs are short-circuit protected.
RECOMMENDED OPERATING CONDITIONS
PARAMETER
VDD Supply voltage
CONDITION
MIN
4.5
NOM
5
MAX
5.5
UNIT
V
TA, Operating Free-Air
Temperature
-40
+85
°
C
Clock Variation
(11.0592 MHz) Crystal or
external clock
-0.01
+0.01
%
External Components
(Refer to Application section for placement.)
VREF Bypass Capacitor
Bias setting resistor
(External to GND)
0.1
1.8
μF
M
(Placed between VDD and
ISET pins)
(ISET pin to GND)
2
2.2
ISET Bypass Capacitor
0.1
μF
VDD Bypass Capacitor 1
(External to GND)
0.1
μF
VDD Bypass Capacitor 2
XTL1 Load Capacitor
(External to GND)
22
μF
pF
40
XTL2 Load Capacitor
Depends on crystal
characteristics; from pin to GND
20
