www.vishay.com
For technical questions, contact: diodes-tech@vishay.com
Document Number: 94244
2
Revision: 13-Aug-08
63CPQ100PbF
Vishay High Power Products
Schottky Rectifier, 2 x 30 A
Note
(1) Pulse width < 300 s, duty cycle < 2 %
ELECTRICAL SPECIFICATIONS
PARAMETER
SYMBOL
TEST CONDITIONS
VALUES
UNITS
Maximum forward voltage drop per leg
See fig. 1
VFM (1)
30 A
TJ = 25 °C
0.77
V
60 A
0.92
30 A
TJ = 125 °C
0.64
60 A
0.76
Maximum reverse leakage current per leg
See fig. 2
IRM (1)
TJ = 25 °C
VR = Rated VR
0.3
mA
TJ = 125 °C
25
Threshold voltage
VF(TO)
TJ = TJ maximum
0.38
V
Forward slope resistance
rt
5.75
m
Ω
Maximum junction capacitance per leg
CT
VR = 5 VDC (test signal range 100 kHz to 1 MHz) 25 °C
1300
pF
Typical series inductance per leg
LS
Measured lead to lead 5 mm from package body
7.5
nH
Maximum voltage rate of change
dV/dt
Rated VR
10 000
V/s
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER
SYMBOL
TEST CONDITIONS
VALUES
UNITS
Maximum junction and storage
temperature range
TJ, TStg
- 55 to 175
°C
Maximum thermal resistance,
junction to case per leg
RthJC
DC operation
See fig. 4
0.8
°C/W
Maximum thermal resistance,
junction to case per package
DC operation
0.4
Typical thermal resistance,
case to heatsink
RthCS
Mounting surface, smooth and greased
0.25
Approximate weight
6g
0.21
oz.
Mounting torque
minimum
6 (5)
kgf cm
(lbf in)
maximum
12 (10)
Marking device
Case style TO-247AC (JEDEC)
63CPQ100
