–3–
REV. A
ADG408/ADG409
SINGLE SUPPLY1
B Version
T Version
–40 C to
–55 C to
Parameter
+25 C
+85 C
+25 C +125 C
Units
Test Conditions/Comments
ANALOG SWITCH
Analog Signal Range
0 to VDD
V
RON
90
typ
VD = +3 V, +10 V, IS = –1 mA
LEAKAGE CURRENTS
Source OFF Leakage IS (OFF)
±0.5
±50
±0.5
±50
nA max
VD =8 V/0 V, VS = 0 V/8 V;
Test Circuit 2
Drain OFF Leakage ID (OFF)
VD =8 V/0 V, VS = 0 V/8 V;
ADG408
±1
±100
±1
±100
nA max
Test Circuit 3
ADG409
±1
±50
±1
±50
nA max
Channel ON Leakage ID, IS (ON)
VS = VD = 8 V/0 V;
ADG408
±1
±100
±1
±100
nA max
Test Circuit 4
ADG409
±1
±50
±1
±50
nA max
DIGITAL INPUTS
Input High Voltage, VINH
2.4
V min
Input Low Voltage, VINL
0.8
V max
Input Current
IINL or IINH
±10
A max
VIN = 0 or VDD
CIN, Digital Input Capacitance
8
pF typ
f = 1 MHz
DYNAMIC CHARACTERISTICS
2
tTRANSITION
130
ns typ
RL = 300 , CL = 35 pF;
VS1 = 8 V/0 V, VS8 = 0 V/8 V;
Test Circuit 5
tOPEN
10
ns typ
RL = 300 , CL = 35 pF;
VS = +5 V; Test Circuit 6
tON (EN)
140
ns typ
RL = 300
, C
L = 35 pF;
VS = +5 V; Test Circuit 7
tOFF (EN)
60
ns typ
RL = 300
, C
L = 35 pF;
VS = +5 V; Test Circuit 7
Charge Injection
5
pC typ
VS = 0 V, RS = 0 , CL = 10 nF;
Test Circuit 8
OFF Isolation
–75
dB typ
RL = 1 k
, f = 100 kHz;
VEN = 0 V; Test Circuit 9
Channel-to-Channel Crosstalk
85
dB typ
RL = 1 k
, f = 100 kHz;
Test Circuit 10
CS (OFF)
11
pF typ
f = 1 MHz
CD (OFF)
f = 1 MHz
ADG408
40
pF typ
ADG409
20
pF typ
CD, CS (ON)
f = 1 MHz
ADG408
54
pF typ
ADG409
34
pF typ
POWER REQUIREMENTS
IDD
11
A typ
VIN = 0 V, VEN = 0 V
55
A max
IDD
100
A typ
VIN = 0 V, VEN = 2.4 V
200
500
200
500
A max
NOTES
1Temperature ranges are as follows: B Version: –40
°C to +85°C; T Version: –55°C to +125°C.
2Guaranteed by design, not subject to production test.
Specifications subject to change without notice.
(VDD = +12 V, VSS = 0 V, GND = 0 V, unless otherwise noted)
