DUAL-IN-LINE SOCKETS
Vertical Display Sockets
(See also page 61 for Right Angle DIP Sockets)
www.mill-max.com
516-922-6000
62
Series 296, 299, 594
&//402).4
SPECIFY PLATING CODE XX=
99
44
200
μ” Sn/Pb 200μ”Sn
200
μ” Sn/Pb 200μ”Sn
Fig. 1
Fig. 2
Fig. 3
1
Fig.
2
10
Sleeve (Pin)
Contact (Clip)
Series 296, 299 & 594 vertical display sockets
are used to mount dot matrix and 7-segment
LED displays at the edge of and perpendicular to
a printed circuit board. This positions the display
directly behind the translucent front panel of the
equipment.
Series 299 & 594 are through hole mount and
can be wave or intrusive reflow soldered.
Series 296 is surface mount and can be sup-
plied on carrier tape for automated “pick ‘n place”
assembly.
Insulators are high temp. Nylon 46, suitable for
all soldering processes including “l(fā)ead-free”.
Ordering Information
No. of
pins
299-99-210-12-001800
Plating Code
296-XX-010-30-691800
(Discrete sockets)
296-XX-010-30-692800
(Supplied on 24mm wide carrier
tape per EIA-481: 450 per 13” reel)
RoHS
2002/95/EC
For RoHS compliance
select
plating code.
3
20
594-XX-020-01-007032
Plating Code
RoHS
2002/95/EC
For Electrical,
Mechanical & Enviromental
Data, See pg. 4
XX=Plating Code
See Below
