DUAL COLOR INDICATOR LAMP
T-1 3/4 PACKAGE SOLID STATE LAMP
MVL-504B3A
Description
Package Dimensions
Features
l
Green and yellow chips are matched for
uniform light output.
l
Long life-solid state reliability.
l
Low power consumption / I.C. compatible
Absolute Maximum Ratings
@ T
A
=25
GREEN
YELLOW
P
ad
100
60
mW
Peak Forward Current
(1/10 Duty Cycle 0.1ms pulse width)
I
pf
120
80
mA
I
af
30
20
mA
0.4
0.25
mA/
V
R
5
5
V
T
opr
T
stg
02/22/2002
Symbol
-55
to + 100
-55
to + 100
Unit
Lead Soldering Temperature : 1.6 mm from body at 260
for 3 seconds
The MVL-504B3A is a water clear narrow viewing
angle,
dual
chips,
utilizing
Gallium
Arsenide
Phosphide on Gallium Phosphide yellow light emitting
diode and Gallium Phosphide on Gallium Phosphide
The green and yellow operating independently of
each other with a common cathode.
green light emitting diode.
Parameter
Maximum Rating
Operating Temperature Range
Storage Temperature Range
Power Dissipation
Continuous Forward Current
Reverse Voltage
Derating Linear From 50
Unity Opto Technology Co., Ltd.
Notes :
1. Tolerance is ± 0.25 mm (.010") unless otherwise noted.
2. Protruded resin under flange is 0.8 mm (.031") max.
3. Lead spacing is measured where the leads emerge from the package.
Unit: mm ( inches )
Center Leads
COMMON CATHODE
Green
ANODE
Yellow
ANODE
SEE NOTE 2
1.70±0.50
(.067±.020)
8.60
(.339)
5.00
(.197)
1.00
(.039)
22.00 MIN.
(.866)
0.50 TYP.
(.020)
2.54 NOM.
(.100)
2.54 NOM.
(.100)
2.00 MIN.
(.079)
4.00 MIN.
(.157)
5.85
(.230)
