SILICON PLANAR EPITAXIAL
PNP TRANSISTOR
2N2904
Semelab Limited
Coventry Road, Lutterworth, Leicestershire, LE17 4JB
Telephone +44 (0) 1455 556565
Fax +44 (0) 1455 552612
Email: sales@semelab-tt.com
Website: http://www.semelab-tt.com
Document Number 3062
Issue 3
Page 2 of 3
ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise stated)
Symbols
Parameters
Test Conditions
Min.
Typ
Max.
Units
V(BR)CEO
(1)
Collector-Emitter
Breakdown Voltage
IC = -10mA
IB = 0
-40
V(BR)CBO
Collector-Base
Breakdown Voltage
IC = -10A
IE = 0
-60
V(BR)EBO
Emitter-Base Breakdown
Voltage
IE = -10A
IC = 0
-5
V
ICEX
Collector Cut-Off Current
VCE = -30V
VBE = -0.5V
-50
nA
VCB = -50V
IE = 0
-0.02
ICBO
Collector Cut-Off Current
TA = 150°C
-20
A
IC = -150mA
IB = -15mA
-0.4
VCE(sat)
(1)
Collector-Emitter Saturation
Voltage
IC = -500mA
IB = -50mA
-1.6
IC = -150mA
IB = -15mA
-1.3
VBE(sat)
(1)
Base-Emitter Saturation
Voltage
IC = -500mA
IB = -50mA
-2.6
V
IC = -0.1mA
VCE = -10V
20
IC = -1.0mA
VCE = -10V
25
IC = -10mA
VCE = -10V
35
IC = -150mA
VCE = -10V
40
120
hFE
(1)
Forward-current transfer
ratio
IC = -500mA
VCE = -10V
20
DYNAMIC CHARACTERISTICS
IC = -50mA
VCE = -20V
fT
Transition Frequency
f = 100MHz
170
MHz
VCB = -10V
IE = 0
Cobo
Output Capacitance
f = 1.0MHz
8
VEB = -2V
IC = 0
Cibo
Input Capacitance
f = 1.0MHz
30
pF
IC = -150mA
VCC = -30V
ton
Turn-On Time
IB1 = -15mA
45
IC = -150mA
VCC = -30V
toff
Turn-Off Time
IB1 = - IB2 = -15mA
300
ns
Notes
(1)
Pulse Width ≤ 300us, δ ≤ 2%
