Chip Errata
DSP56301 Digital Signal Processor
Mask:2K30A
DSP56301 Errata
1996-2002, Motorola
For More Information On This Product,
Go to: www.freescale.com
ng 12/19/02 pg. 3
ED4
Description (added 10/ 09/ 1997):
The following instructions should not start at address LA:
MOVE to/ from Program space {MOVEM, MOVEP (only the P
space options)}
This is not a bug but a documentation update (Appendix B,
DSP56300 Family Manual).
Description (added 4/ 13/ 98):
2K30A
ED6
When the HIRQ pin is used in pulse mode (HIRH=0 in DCTR), the
LT[7:0] value (in CLAT) should not be zero. This is not a bug but a
documentation update.
Description (added 1/ 27/ 98):
2K30A
ED7
When activity passes from one DMA channel to another and the
DMA interface accesses external memory (which requires one or
more wait states), the DACT and DCH status bits in the DMA
Status Register (DSTR) may indicate improper activity status for
DMA Channel 0 (DACT = 1 and DCH[2:0] = 000).
Workaround:
None.
Pertains to:
DSP56300 Family Manual, Sections 8.1.6.3 and 8.1.6.4
Description (added 10/ 09/ 1997):
2K30A
ED8
The timing for HSAK is no longer qualified by the data strobe. The
new timing numbers are:
a.
T318
—
HSAK assertion from HA0
–
HA10 and HAEN valid is
30.0 ns maximum.
b.
T319
—
HSAK assertion hold from HA0-HA10 and NAEN not
valid is 2.0 ns minimum.
This is not a bug, but a documentation update of a specification
change.
2K30A
Errata
Number
Document Update
Applies
to Mask
F
Freescale Semiconductor, Inc.
n
.
