BUCHANAN Terminal Blocks
Material & Finish
Connector:
Housing Material—Thermoplastic
polyester
Flammability—UL94V-0
Terminals—Copper alloy, selective
gold over nickel
Application Data—2M50TELS(P)
Complies with SCSI Connections
Terminal Block:
Housing Material—Thermoplastic
polyester
Flammability—UL94V-0
Color—Black
Max. Operating Temperature—
120°C [248°]
Terminals—Bright acid-tin over
copper alloy
Screws—#3-48, steel zinc plated
Wire Range—12-22 AWG
Mounting—2TK2 and 2TK2D Series
SNAPTRACK Channel
Non RoHS Compliant
No. of
Dim.
Socket
Plug
Positions
C
Part Number Catalog Number
36
4.30 (109.2)
2-1437684-1
2M36TELS
—
2M36TELP
50
5.70 (144.8)
3-1437684-2
2M50TELS
3-1437684-1
2M50TELP
29,9
(1.18)
C
71,1
(2.8)
76,2
(3.0)
RoHS Compliant
No. of
Dim.
Socket
Plug
Positions
C
Part Number Catalog Number
36
4.30 (109.2)
1776826-1
2M36TELSL
—
2M36TELPL
50
5.70 (144.8)
1776604-1
2M50TELSL
1776643-1
2M50TELPL
