Star Point Relay SPR
(Continued)
10-2012, Rev. 1012
www.te.com
2011 Tyco Electronics Corporation,
a TE Connectivity Ltd. company.
Datasheets and product specification ac-
cording to IEC 61810-1 and to be used only
together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
2
Automotive Relays
High Current Devices
Insulation Data
Initial dielectric strength
between contact and coil
500VAC
rms
Other Data
EU RoHS/ELV compliance
Ambient temperature
Cold storage, IEC 60068-2-1
Dry heat, IEC 60068-2-2
Temperature cycling (shock),
IEC 60068-2-14, Na
Damp heat cyclic,
IEC 60068-2-30, Db, Variant 1
Flowing mixed gas corrosion test,
IEC 60068-2-60, Ke, method 1
Degree of protection
Vibration resistance (functional),
IEC 60068-2-64 (random) energized
IEC 60068-2-64 (random) not energized 20 to 1000Hz >4g ms
Shock resistance (functional),
IEC 60068-2-27 (half sine) 6ms, energized
IEC 60068-2-27 (half sine) 6ms, not energized
Mounting
Weight
Packaging unit
compliant
-40°C to 125°C
2000h; -40°C
500h; +135°C
500 cycles; -40/+135°C
83 cycles (2000h) 25°C/55°C/93%RH
IP67 (IEC 60529), RT III (IEC 61810)
10 days
20 to 1000Hz >6g ms
>40g
>10g
welding process on leadframe
approx. 30g (1.06oz)
357 pcs.
1 form 3, 3 NO
Terminal Assignment
3
5
4
1
2
Dimensions
View of the terminals
Bottom view
1) Epoxy at terminals exceeds max. 0.9mm over
coverage.
2) Permanent acceptable deformation 0.25mm
respectively 0.5mm temporarily.
Maximum permissible thermal load of the
terminals during the resistance welding process
depends on leadframe design.
