10-2012, Rev. 1012
www.te.com
2011 Tyco Electronics Corporation,
a TE Connectivity Ltd. company.
Datasheets and product specification ac-
cording to IEC 61810-1 and to be used only
together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
1
n
Full, symmetric star-point disconnection of an electric power
steering motor
n
Limiting continuous current 90A at 85°C
n
Disconnection of high over-currents up to 200A in 12VDC and up to
60A in 36VDC power nets
n
Contact arrangement fulfills 42VDC power net requirements
n
Optimized dimensions: lhw (in mm) 32x18.5x18
n
Resistant against high ambient temperature up to 125°C
n
Contact resistance typ. <2m per path for load current 20A after
fritting
Typical applications
All EPA/EPS applications.
Contact Data
Contact arrangement
Rated voltage
Max. switching voltage
Rated current
Limiting continuous current
1)
23°C
85°C
125°C
Limiting breaking current
Breaking capacity max.
Contact material
Contact style
Min. recommended contact load
5)
Initial voltage drop, after fritting with 90A for 30s <180mV at 90A
Operate/release time max.
3)
Bounce time max.
3)
Electrical endurance
120A, dry switching
4)
at 23°C, 500ms on/off >2x10
5
ops.
Mechanical endurance
1 form 3, 3 NO
12VDC
depends on load parameters
A)
200A
2)
>10 ops. at 200A
1A at 5VDC
120A
120A
90A
60A
AgNi0.15
triple
<20/10ms
see footnote
3)
>10
6
ops.
Contact Data
(continued)
A) Please contact TE relay application engineer.
1) Max. terminal temperatures up to 180°C are allowed. Final temperatures depend on the
leadframe layout.
2) Without relay coil voltage: suppression component (see Application Note “Automotive
Applications”.
3) Release and bounce time depend on component in parallel to the coil, please contact
application support.
4) Load only carried, not switched!
5) See Application Note “Diagnostics of Relays”
Coil Data
Coil voltage range
Max. coil temperature
12VDC
<180°C
Coil versions, DC coil
Coil
code
001
002
All figures are given for coil without preenergization, at ambient temperature +23°C.
Coil operating range
Rated
voltage
VDC
12
10
Operate
voltage
VDC
6.4
5.2
Release
voltage
VDC
1
0.8
Coil
Rated coil
power
W
0.96
1.03
resistance
±10%
150
97
Star Point Relay SPR
Automotive Relays
High Current Devices
Max. DC load breaking capacity
Load limit Curve II: valid for load path through pin 4 and pin 5, no coil suppression used.
Andreas Hendler
Seite 1
13.10.2010
10
100
1000
1
10
100
1000
Load Current [A]
L
0
1
2
3
4
5
6
7
8
9
10
-40
-20
0
20
40
60
80
100
120
140
160
180
V
Coil Temperature [°C]
23
°
Uop 002 (E=0V)
Uop 001 (E=0V)
Urel 002
Urel 001
Does not take into account the temperature rise due to the contact current
E = pre-energization
F135_fcw3b
