Slim Line Hybrid for Infineon
0803-6500-20
PROTECTION CIRCUIT - COMPONENT SPECIFICATIONS
Two element line side (over voltage/over current) protection scheme designed to meet Telecordia GR1089.
LINE SIDE OVER VOLTAGE PROTECTION
Discrete longitudinal solution using semiconductor devices.
Peak Off
State Voltage
Switching
Voltage
On State
Voltage
Leakage
Current
A
Switching
Current
max
On State
Current
Holding
Current
mA
Off State
Capacitance
pF
160V
220V
5V
5
800A
1A
150
40
O/V PROTECTION DEVICE RATINGS
LINE SIDE OVER CURRENT PROTECTION
Surface mount power cross protection fuses designed to meet UL 1950/60950 & Telcordia GR1089.
Ampere Rating
Voltage Rating
DCR
Voltage Drop@ I
max
Peak Surge
Current
Maximum Power
Dissipation
1.25A
600V
0.090
0.18V
100
0.4W
FUSE RATINGS
CHIP SIDE OVER VOLTAGE PROTECTION
Diode over voltage protection provided with respect to GND and VCC.
DIODE RATINGS
VRRM
max
IF (AV)
mA max
IFSM
max
TSTG
TJ
max
PD
max
VR
max
VF
IR
CT
200V
200
1A
-55° to +150° C
150°
200V
1.1V @
0.87A min
5uA @
180V max
4pF @
1MHz max
