Physical
Circuits (Loaded)
110
Circuits (maximum)
110
Color - Resin
Gray
Durability (mating cycles max)
125
First Mate / Last Break
No
Flammability
94V-0
Guide to Mating Part
No
Keying to Mating Part
Yes
Material - Plating Mating
Gold
Material - Plating Termination
Tin-Lead
Material - Resin
Polyester
Number of Columns
N/A
Number of Pairs
Open Pin Field
Number of Rows
5
Orientation
Right Angle
PCB Retention
None
PCB Thickness Recommended (in)
0.055 In, 0.060 In, 0.061 In, 0.062 In, 0.070 In, 0.075 In, 0.080
In, 0.086 In, 0.093 In, 0.098 In, 0.102 In, 0.110 In, 0.120 In,
0.125 In, 0.134 In, 0.140 In, 0.150 In, 0.153 In, 0.157 In, 0.161
In, 0.165 In
PCB Thickness Recommended (mm)
1.40 mm, 1.50 mm, 1.55 mm, 1.60 mm, 1.80 mm, 1.90 mm,
2.00 mm, 2.20 mm, 2.40 mm, 2.50 mm, 2.60 mm, 2.80 mm,
3.00 mm, 3.20 mm, 3.40 mm, 3.60 mm, 3.80 mm, 3.90 mm,
4.00 mm, 4.10 mm, 4.20 mm
Packaging Type
Tube
Pitch - Mating Interface (in)
0.079 In
Pitch - Mating Interface (mm)
2.00 mm
Plating min: Mating (in)
32
Plating min: Mating (m)
0.8
Plating min: Termination (in)
20
Plating min: Termination (m)
0.5
Polarized to PCB
Yes
Stackable
Yes
Surface Mount Compatible (SMC)
No
Temperature Range - Operating
-55°C to +125°C
Termination Interface: Style
Through Hole - Compliant Pin
Electrical(Please review the Product Specification for specific details.)
Current - Maximum per Contact
1A
Data Rate
622.0 Mbps
Real Signals (per 25mm)
40
Voltage - Maximum
500V
Molex Connector Part Number - 0553511109
Page 3 of 4
C:\TEMP\04192010\MOLE\0553511109.mht
20-Apr-2010
