| 型號： | 0533970849 |
| 廠商： | MOLEX INC |
| 元件分類： | 電路板相疊連接器 |
| 英文描述： | 84 CONTACT(S), MALE, STRAIGHT BOARD STACKING CONNECTOR, SURFACE MOUNT, PLUG |
| 文件頁數： | 3/4頁 |
| 文件大?。?/td> | 153K |
| 代理商： | 0533970849 |
Physical
Breakaway
No
Circuits (Loaded)
84
Circuits (maximum)
84
Color - Resin
Natural
Durability (mating cycles max)
50
Flammability
94V-0
Glow-Wire Compliant
No
Lock to Mating Part
Yes
Mated Height (in)
0.394 In
Mated Height (mm)
10.00 mm
Material - Resin
High Temperature Thermoplastic
Number of Rows
2
Orientation
Vertical
PC Tail Length (in)
0.021 In
PC Tail Length (mm)
0.53 mm
PCB Locator
Yes
PCB Retention
None
Packaging Type
Tube
Pitch - Mating Interface (in)
0.039 In
Pitch - Mating Interface (mm)
1.00 mm
Polarized to PCB
No
Shrouded
Fully
Temperature Range - Operating
-55°C to +85°C
Electrical(Please review the Product Specification for specific details.)
Current - Maximum per Contact
0.5A
Voltage - Maximum
100V
Agency Certification
CSA
LR19980
UL
E29179
Material Info
Reference - Drawing Numbers
Product Specification
PS-52584-002
Molex Connector Part Number - 0533970849
Page 3 of 4
C:\TEMP\04192010\MOLE\0533970849.mht
20-Apr-2010
