參數資料
| 型號： | 0399810417 |
| 廠商： | MOLEX INC |
| 元件分類： | 接線盒 |
| 英文描述： | 10 A, STRIP TERMINAL BLOCK, 1 ROW, 1 DECK |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 1/2頁 |
| 文件大?。?/td> | 26K |
| 代理商： | 0399810417 |
This document was generated on 11/06/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Active
Description:
5.08mm (.200") Pitch Beau Eurostyle Surface Mount Compatible Locking Header,
Gold (Au) Plated, 17 Circuits
Documents:
General
Product Family
Terminal Blocks
Series
Application
Wire-to-Board
Component Type
PCB Header
Product Name
EurostylePluggable
Type
Euro Block
Physical
Circuits (Loaded)
17
Entry Angle
N/A
Lock to Mating Part
Yes
Material - Plating Mating
Gold
Material - Plating Termination
Gold
Number of Rows
1
Orientation
Vertical
PC Tail Length (in)
0.150 In
PC Tail Length (mm)
3.81 mm
PCB Retention
N/A
PCB Thickness Recommended (in)
0.062 In
PCB Thickness Recommended (mm)
1.60 mm
Panel Mount
No
Pitch - Mating Interface (in)
0.200 In
Pitch - Mating Interface (mm)
5.08 mm
Plating min: Mating (in)
30
Plating min: Mating (m)
1.18
Plating min: Termination (in)
30
Plating min: Termination (m)
1.18
Polarized to Mating Part
Yes
Shrouded
No
Stackable
No
Surface Mount Compatible (SMC)
No
Temperature Range - Operating
140°C
Termination Interface: Style
Through Hole
Wire Size AWG
N/A
Electrical
Current - Maximum
10A
Voltage - Maximum
300V
Material Info
Old Part Number
981517-G30
Reference - Drawing Numbers
Sales Drawing
SD-39980-006
Series image - Reference only
ELV and RoHS
Compliant
Not Reviewed
Not Reviewed
Need more information on product
environmental compliance?
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
39981 Series
Mates With
39981-0317 Screw Clamp Plug
This document was generated on 11/06/2009
