www.tracopower.com
Page 2
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
Input Specifications
Input current
(no load)
Input current
(at full load) TSI-3.3S2 models
all models
2 mA max.
1410 mA max.
(5 Vin)
890 mA max.
(12 Vin)
TSI-5.0S2 models
Stand-by current
Output Specifications
100 μA max.
Voltage adjustment
TSI-3.3S2 models
TSI-5.0S2 models
+1.8 VDC to +3.3 VDC
+3.0 VDC to +5.0 VDC
Regulation
– Input variation
– Load variation 0 – 100 %
± 0.5 %
< 1.5 %
Ripple and noise
(20 MHz Bandwidth)
50 mVpk-pk max.
Transient response time
TSI-3.3S2 models
50% Load change:
Vout over-/ undershoot:
70 mV typ.
50% Load change:
Vout over-/ undershoot:
80 mV typ.
100 μsec typ.
TSI-5.0S2 models
100 μsec typ.
Temperature coefficient
± 0.01 % / °C
Short circuit protection
constant current >105%
Remote ON/OFF control
ON=Pin 1
(ON/ OFF Pin)
to pin 3
(GND)
open
OFF=Pin 1
(ON/ OFF Pin)
to pin 3
(GND)
short
General Specifications
Temperature ranges
– Operating
– Storage
Derating above 50°C
– 25 °C ... +70 °C
– 25 °C ... +85 °C
3 % / °C
Humidity
(non condensing)
95 % rel H max.
Reliability, calculated MTBF
(MIL-HDBK-217 E)
>1’000’000 h @ 50 °C
Isolation
Input/ Output
none
Switching frequency
Physical Specifications
200 kHz typ. (PWM modulation)
Vibration
5 to 10 Hz amplitude 10 mm pk-pk
10 to 55 Hz acceleration 2 G
Shock
acceleration 20 G max. time 11 ms
Package weight
6 g
Soldering temperature
max. 235°C max. / 10 sec.
DC/DC Converter
TSI-10 Series 10 Watt
