| 型號： | M38C59MF-XXXHP |
| 元件分類： | 微控制器/微處理器 |
| 英文描述： | 8-BIT, MROM, 6.25 MHz, MICROCONTROLLER, PQFP80 |
| 封裝： | 12 X 12 MM, 0.50 MM PITCH, PLASTIC, LQFP-80 |
| 文件頁數： | 61/75頁 |
| 文件大?。?/td> | 995K |
| 代理商： | M38C59MF-XXXHP |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁第60頁當前第61頁第62頁第63頁第64頁第65頁第66頁第67頁第68頁第69頁第70頁第71頁第72頁第73頁第74頁第75頁
Rev.2.00
Nov 23, 2005
page 64 of 73
REJ03B0028-0200
38C5 Group
“H” total peak output current (Note 1)
P00–P07, P10–P17, P20–P27, P30–P37, P72–P74
“H” total peak output current (Note 1)
P40–P47, P50–P57, P60–P67
“L” total peak output current (Note 1)
P00–P07, P10–P17, P20–P27, P30–P37, P72–P74
“L” total peak output current (Note 1)
P40–P47, P50–P57, P60, P61
“L” total peak output current (Note 1)
P62–P67
“H” total average output current (Note 1)
P00–P07, P10–P17, P20–P27, P30–P37, P72–P74
“H” total average output current (Note 1)
P40–P47, P50–P57, P60–P67
“L” total average output current (Note 1)
P00–P07, P10–P17, P20–P27, P30–P37, P72–P74
“L” total average output current (Note 1)
P40–P47, P50–P57, P60, P61
“L” total average output current (Note 1)
P62–P67
“H” peak output current (Note 2)
P00–P07, P10–P17, P20–P27, P30–P37
“H” peak output current (Note 2)
P40–P47, P50–P57, P60–P67, P72–P74
“L” peak output current (Note 2)
P00–P07, P10–P17, P20–P27, P30–P37
“L” peak output current (Note 2)
P40–P47, P50–P57, P60, P61, P72–P74
“L” peak output current (Note 2)
P62–P67
“H” average output current (Note 3)
P00–P07, P10–P17, P20–P27, P30–P37
“H” average output current (Note 3)
P40–P47, P50–P57, P60–P67, P72–P74
“L” average output current (Note 3)
P00–P07, P10–P17, P20–P27, P30–P37
“L” average output current (Note 3)
P40–P47, P50–P57, P60, P61, P72–P74
“L” average output current (Note 3)
P62–P67
ΣIOH(peak)
ΣIOL(peak)
ΣIOH(avg)
ΣIOL(avg)
IOH(peak)
IOL(peak)
IOH(avg)
IOL(avg)
Limits
mA
Parameter
Min.
Typ.
Max.
Symbol
Unit
–40
40
110
–20
20
90
–2
–5
5.0
10
30
–1.0
–2.5
2.5
5.0
15
Table 13 Recommended operating conditions (Mask ROM version)
(Vcc = 1.8 to 5.5 V, Ta = –20 to 85°C, unless otherwise noted)
Notes 1: The total output current is the sum of all the currents flowing through all the applicable ports. The total average current is an average value measured over
100 ms. The total peak current is the peak value of all the currents.
2: The peak output current is the peak current flowing in each port.
3: The average output current is average value measured over 100 ms.
